OMI6712A
12.1" Panel PC, 2 Ethernet Ports, 2 USB Ports, 2 Serial Ports, 1 Audio Out, Intel Atom 1.6GHz, 2GB RAM, 800 x 600 Resolution
List Price Starts At : $1,345.00
As part of our Panel PC Series, this model provides a high-quality option for applications requiring a Windows® Operating System. With Windows® Embedded Standard 7, this PC supports 3rd party and SCADA software like our Indusoft Web Studio®. Looking for more memory or faster processor? Check out the OMI6800 and OMI6900 Series in this same family.
Software: Web Studio®
To buy this product please call us at (425) 745-3229 or email us at sales@maplesystems.com
At a Glance:
  • 800x600 Resolution
  • Intel Atom N2600 1.6GHz Dual Core Processor
  • 2GB RAM, 32GB MLC SSD
  • Microsoft Windows® Embedded Standard 7, 32 or 64-bit, upgrade available
  • Additional Memory and Wi-Fi Kit upgrades available
  • Aluminum Enclosure
  • Integrate with Indusoft's Web Studio®
Customers Also Purchased
Power Supply & Connectors
Input Power Connector
For OMI/Box PC Only
2140-0308
$5.00
Power Supply & Connectors
Power Supply, Single Output, DIN Rail, 24VDC, 1.7A
For all products, except Industrial PC
4010-0010
$35.00
Power Supply & Connectors
Power Supply, Single Output, DIN Rail, 24VDC, 2.5A
For all products, except Industrial PC
4010-0011
$45.00
Power Supply & Connectors
Power Supply, Single Output, DIN Rail, 24VDC, 4A
For all products, except PC400's
4010-0013
$65.00
Cable & Adapters
Cable, CAT5E Ethernet, 5'
For all products with Ethernet
7431-0103
$10.00
Cable & Adapters
Cable, CAT5E Ethernet, Crossover, 5'
For all products with Ethernet
7431-0104
$10.00
Cable & Adapters
Adapter, PC USB 2.0/3.0 to Ethernet
For all products with Ethernet port
7433-0005
$35.00
Cable & Adapters
We offer Custom Communication Cables to interface with over 300 protocols.
Call to place your Custom Cable order, or refer to our Support Center for a complete list.
Mounting Clips
Mounting Clips Kit for OMI (each)
For OMI6000 Series (all sizes except 7.0" and 10.0" models)
2860-0012
$4.00
Miscellaneous
4 GB SD Card
For all models with standard SD Card slot.
2064-0001
$20.00
View All Accessories
More Information about the OMI6712A
Maple Systems Panel and Boxed PC series are the perfect solution for OEMs requiring a high performance, low-cost, Industrial PC to run custom applications. State-of-the-art architecture includes Intel processors and more memory.
Optional Upgrades Available  Read More >


Heavy Industrial PC Hardware Features
Maple Systems Heavy Industrial Panel PC's state-of-the-art architecture includes Intel processors, more memory, and fan and fan-less models to meet your requirements. All our Industrial PCs feature an aluminum bezel and enclosure and are built to withstand the harsh environments found in industrial sites. Each unit is fully certified to meet European CE standards for noise emission/immunity.

FAN - PC400 Models:
  • 15", 17", and 19" touchscreens
  • Intel® Dual-Core processor G630T, 2.3 GHz
  • 4 GB memory
  • 320 GB HD, upgradable to 500 GB
  • 5 serial ports
  • 4 USB 2.0 (19" has 6x USB 2.0)
  • 2 USB 3.0 ports
  • 2 Ethernet LAN, 2 SFP Optical ports
  • Aluminum Bezel and Steel Enclosure
  • NEMA4, CE, FCC, RoHS, and IP66 compliant

FANLESS - PC2300 Models:
  • 15", 17", and 19" touchscreens
  • Intel® Core Mobile i3-3120ME, upgrades available
  • 4 GB memory, upgrades available
  • 500 GB HD, upgrades available
  • 4 serial ports
  • 4 USB ports
  • 2 Ethernet LAN
  • Aluminum Bezel and Enclosure
  • NEMA4, CE, FCC, RoHS, and IP65 compliant



Industrial Panel PC Hardware Features
Maple Systems Panel PCs are the perfect solution for OEMs requiring a high performance, low-cost Industrial Panel PC to run custom applications. State-of-the-art construction includes Intel processors, Die-cast aluminum enclosures, and more memory compared to prior models.

OMI6700 Models:
  • 7", 10.1", 12.1", & 15" screen displays
  • Analog resistive touchscreen
  • Intel Atom N2600 1.6 GHz processor
  • 2 GB of memory
  • 32~512 GB MLC Solid State Hard Drive
  • Fan-less
OMI6800 Models:
  • 7", 10.1", 12.1", 15", 15.6", 18.5", & 21.5" screen displays
  • Analog resistive touchscreen
  • Intel Celeron N2930 1.83 GHz processor
  • 4 GB of memory
  • 64~512 GB MLC Solid State Hard Drive
  • Optional Wi-Fi Kit available
  • Fan-less
OMI6900 Models:
  • 12.1", 15", 15.6", 18.5", & 21.5" screen displays
  • Analog resistive touchscreen
  • Intel 4th Gen Core i5 processor
  • 8 GB of memory
  • 64~512 GB MLC Solid State Hard Drive
  • Optional Wi-Fi Kit available
  • Fan-less


Box PC Hardware Features
Looking for a powerful Industrial PC, but don't need a display? Our Box Industrial PCs are the perfect combination of performance and sturdy construction at a low-cost. This model can be paired with one of our Industrial Monitor.

BPC2310A/BPC2311A
  • Intel® Celeron N2930 1.83GHz processor
  • 4 GB memory, optional upgrade to 8 GB memory
  • 64~512 GB Solid State Hard Drive
  • 2 or 3 serial ports
  • 6 USB ports
  • 2 Ethernet LAN
  • Aluminum Bezel and Enclosure
  • Wall Mount or DIN-rail Mount options
  • Optional Wi-Fi Kit available
  • Fan-less

BPC2330A
  • Intel® Dual Core i3-7101TE @ 3.4GHz, upgrades available
  • Up to 32 GB DDR4 SO-DIMM RAM
  • Two 2.5" SSD bays, RAID 0 and RAID 1 support
  • 4 serial ports
  • 6 USB ports
  • 4 Ethernet LAN
  • Aluminum Bezel and Enclosure
  • Optional Wi-Fi Kit available
  • Fan-less



Industrial HMI Hardware Features
Our Industrial Panel or VESA mount HMIs with Windows Embedded Compact 7 (formally known as CE) offer a lightweight Windows operating system that can be paired with Web Studio or a SCADA software of your choice for automation processes that require specific capabilities and customization.

OMI6500 Models:
  • 7", 10.1", & 12.1" screen displays
  • Analog resistive touchscreen
  • TI-AM3354, ARM Cortex A8 processor 1 GHz CPU
  • 512 MB Flash / 512 MB DRAM
  • Fan-less
  • Panel or VESA mount
  • Plastic Enclosure





Windows®-Compatible Options


The Windows® platform allows configuration with many Windows® - compatible applications, thus providing you with capabilities beyond proprietary HMI configuration software. Refer to the specific Industrial PC model fro the base operating System included and upgrade options available.


Windows® Embedded Standard 7


Windows® Embedded Standard 7 (WS7P) has a smaller footprint than full Windows® and is perfect for applications that require additional software such as the Windows® Office suite.
Included Apps:
  • Internet Explorer
  • MS Word Viewer
  • Adobe PDF Viewer
  • MS PowerPoint Viewer
  • MS Excel Viewer
  • Media Player


Windows® 7 Pro for Embedded Systems


Windows® 7 Pro for Embedded Systems (FES 7 Pro) is a full version of Windows® 7 Pro. This powerful operating system will run any program that will run on a PC, including in XP mode. All of the features and functionality that customers expect to find on their desktop PC are available in this version.
Included Apps:
  • Internet Explorer
  • MS Word Viewer
  • Adobe PDF Viewer
  • MS PowerPoint Viewer
  • MS Excel Viewer
  • Media Player


Microsoft Windows® 10 IoT Enterprise 2016 LTSB for Embedded Systems


Microsoft Windows® 10 IoT Enterprise 2016 LTSB for Embedded Systems is a full Professional version of Windows® 10. This powerful operating system delivers enterprise manageability and security to IoT solutions. Additionally, all of the features and functionality that customers expect to find on their desktop PC are available in this version. The Long Term Servicing Branch (LTSB) version ensures long term stability that critical production systems require by updating only necessary operating system components, with significantly fewer update interruptions.
Included Apps:
  • Internet Explorer
  • MS Word Viewer
  • Adobe PDF Viewer
  • MS PowerPoint Viewer
  • MS Excel Viewer
  • Media Player




As a total solution to your industrial automation needs, we recommend Web Studio®, a powerful and intuitive HMI/SCADA software for Panel PCs. Web Studio® provides a media-rich operating environment that clearly communicates system conditions to operators. It also allows supervisors and engineers to view and modify data remotely.

Software Features

Web Studio® enables you to:
  • Create real-time applications that support animated graphic screens, trends, alarms, reports, and recipes
  • Utilize sophisticated security features for system protection
  • Utilize the Internet to remotely view multiple applications
  • Connect with more than 250 communication drivers for PLCs and controllers
  • Provide OPC (client & server) support

For more information about Indusoft Web Studio® and pricing, click here

Click below for more information.
Please use the following links for product-specific certifications:

For more information on this product, please see the following resources:
Brochure

Manuals
Additional Resources
12.1" OMI6812A • Industrial PC Series
12.1" Panel PC, 2 Ethernet Ports, 2 USB Ports, 2 Serial Ports, 1 Audio Out, Intel Celeron 1.83GHz, 4GB RAM, 800 x 600 Resolution
List Price Starts At : $1,395.00
At a Glance:
  • 800x600 Resolution
  • Intel Celeron N2930 1.83GHz Quad Core Processor
  • 4GB RAM, 32GB MLC SSD
  • Microsoft Windows® 10 IoT Ent Embedded 32or 64-bit, upgrades available
  • Additional Memory and Wi-Fi Kit upgrades available
  • Aluminum Enclosure
  • Integrate with Indusoft's Web Studio®
12.1" OMI6912A • Industrial PC Series
12.1" Panel PC, 2 Ethernet Ports, 2 USB Ports, 2 Serial Ports, 1 Audio Out, Intel i5 1.9GHz, 8GB RAM, 800 x 600 Resolution
List Price Starts At : $2,195.00
At a Glance:
  • 800x600 Resolution
  • Intel 4th Gen Core i5-4300U CPU Processor
  • 8GB RAM, 32GB MLC SSD
  • Microsoft Windows® 10 IoT Ent Embedded 32-bit, upgrade available
  • Additional Memory and Wi-Fi Kit upgrades available
  • Aluminum Enclosure
  • Integrate with Indusoft's Web Studio®
