Home > Panel PCs > BPC2330A

Fanless Industrial PC


As part of our Industrial PC Series, this Box PC provides a high-quality option for applications that do not require a fixed display. With a Windows® or Linux® Ubuntu® Operating System, this PC supports 3rd party and SCADA software like our AVEVA® Edge. Pair our Box PC with an Industrial Monitor for greater flexibility.
$1,620.00
Quantity Discounts Available. Contact Sales for more details.
Build your Panel PC using our configuration tool to view price:
At a Glance:
  • Intel Dual Core i3-7101TE @3.4GHz Processor, upgrades available
  • HDMI®, DVI, and DP
  • Up to 32 GB DDR4 SO-DIMM RAM
  • Two 2.5” SSD bays, RAID 0 and RAID 1 support
  • Steel Chassis, Aluminum Heatsink
  • Wi-Fi Kit upgrade available
  • Integrate with AVEVA Edge 2020,
CE RoHS FCC Class A IP20
Optional Software: AVEVA Edge 2020. Learn More
Case Study
"I’ll always pay more for a quality product that gives me enough extra power and flexibility to accommodate the inevitable increase in scope or performance our customers tend to need."
Ken Roach
Senior Controls Engineer
Fives Lund
Configure your Panel PC
The base options are selected by default. Select the options to the get desired configuration.
Box PC
Box PC -
Processor (CPU)
Intel® Dual Core i3-7101TE, 3.4 GHz 3985 CPU Benchmark   -
Intel® Quad Core i5-7500T, 2.7 GHz 5362 CPU Benchmark   $320
Intel® Quad Core i7-7700T, 2.9 GHz 7898 CPU Benchmark   $690
System Memory (RAM)
8 GB DDR4 260-pin SO-DIMM -
16 GB DDR4 260-pin SO-DIMM $95
32 GB DDR4 260-pin SO-DIMM $275
Storage
64 GB SSD SATA3, MLC (supports RAID 0, RAID 1) -
128 GB SSD SATA3, MLC (supports RAID 0, RAID 1) $45
256 GB SSD SATA3, MLC (supports RAID 0, RAID 1) $155
512 GB SSD SATA3, MLC (supports RAID 0, RAID 1) $300
Operating System
Microsoft® Windows® 10 IoT Enterprise Embedded 2019 LTSC 64-bit (EPKEA)    Value – required for i3 and i5 CPU -
Microsoft® Windows® 10 IoT Enterprise 2019 LTSC 64-bit (PKEA)    Value – required for i3 and i5 CPU $0
Microsoft® Windows® 10 IoT Enterprise Embedded 2019 LTSC 64-bit (EPKEA)    High End – required for i7 CPU $0
Microsoft® Windows® 10 IoT Enterprise 2019 LTSC 64-bit (PKEA)    High End – required for i7 CPU $0
Linux® Ubuntu® Desktop 20.04 LTS     ($50)
Linux® Ubuntu® Server 20.04 LTS     ($50)
Expansion Kit
None -
Wi-Fi 802.11b/g/n $85
Default options highlighted in yellow
Current Configuration
Box PC
Processor (CPU)
Intel® Dual Core i3-7101TE, 3.4 GHz
System Memory (RAM)
8 GB
Storage
64 GB SSD
Operating System
Microsoft® Windows® 10 IoT Enterprise Embedded 2019 LTSC 64-bit (EPKEA)
Expansion Kit
None
Your Part Number:
Qty:
Total:
Specifications
Operating System


As a total solution to your industrial automation needs, we recommend AVEVA Edge 2020, a powerful and intuitive HMI/SCADA software for Panel PCs. AVEVA Edge 2020 provides a media-rich operating environment that clearly communicates system conditions to operators. It also allows supervisors and engineers to view and modify data remotely.

Software Features

AVEVA Edge 2020 enables you to:
  • Create real-time applications that support animated graphic screens, trends, alarms, reports, and recipes
  • Utilize sophisticated security features for system protection
  • Utilize the Internet to remotely view multiple applications
  • Connect with more than 250 communication drivers for PLCs and controllers
  • Provide OPC (client & server) support

For more information about AVEVA Edge 2020 and pricing, click here



Windows®-Compatible Options

The Windows® platform allows configuration with many Windows® - compatible applications, thus providing you with capabilities beyond proprietary HMI configuration software. Refer to the specific Industrial PC model for the base operating System included and upgrade options available.


Microsoft Windows® 10 IoT Enterprise 2019 LTSC for Embedded Systems
Supported Models : See specific product pages for more information

PKEA also known as "Product Key Entry Activation"

The Product Key belongs to the end user and the Product Key sticker is attached to the PC. The end user must activate the OS by logging on to the Microsoft website with the PC and enter the Product Key.

Microsoft Windows® 10 IoT Enterprise 2019 LTSC for Embedded Systems is a full Professional version of Windows® 10. This powerful Operating System delivers enterprise manageability and security to IoT solutions. Additionally, all of the features and functionality that customers expect to find on their desktop PC are available in this version. The Long Term Servicing Channel (LTSC) version ensures long term stability that critical production systems require by updating only necessary operating system components, with significantly fewer update interruptions.

Included Apps:
  • Internet Explorer
  • MS Word Viewer
  • Adobe PDF Viewer
  • MS PowerPoint Viewer
  • MS Excel Viewer
  • Media Player
Microsoft Windows® 10 IoT Enterprise Embedded 2019 LTSC
Supported Models : See specific product pages for more information

EPKEA also known as "Embedded Product Key Entry Activation"

The Product Key is embedded in the PC and activated by Maple Systems. If the OS needs to be reinstalled, it must come back to Maple Systems.

Microsoft Windows® 10 IoT Enterprise Embedded 2019 LTSC is a full Professional version of Windows® 10. This powerful Operating System delivers enterprise manageability and security to IoT solutions. Additionally, all of the features and functionality that customers expect to find on their desktop PC are available in this version. The Long Term Servicing Channel (LTSC) version ensures long term stability that critical production systems require by updating only necessary operating system components, with significantly fewer update interruptions.

Included Apps:
  • Internet Explorer
  • MS Word Viewer
  • Adobe PDF Viewer
  • MS PowerPoint Viewer
  • MS Excel Viewer
  • Media Player
Microsoft Windows® 10 IoT Enterprise 2016 LTSB for Embedded Systems -- by special request only, contact sales to place order.
Supported Models : See specific product pages for more information

Microsoft Windows® 10 IoT Enterprise 2016 LTSB for Embedded Systems is a full Professional version of Windows® 10. This powerful operating system delivers enterprise manageability and security to IoT solutions. Additionally, all of the features and functionality that customers expect to find on their desktop PC are available in this version. The Long Term Servicing Branch (LTSB) version ensures long term stability that critical production systems require by updating only necessary operating system components, with significantly fewer update interruptions.

Included Apps:
  • Internet Explorer
  • MS Word Viewer
  • Adobe PDF Viewer
  • MS PowerPoint Viewer
  • MS Excel Viewer
  • Media Player
FES 7 Pro - For Embedded Systems Windows® 7 Pro
Supported Models : See specific product pages for more information

FES 7 Pro also known as "For Embedded Systems Windows® 7 Pro"

The Product Key belongs to the end user and the Product Key sticker is attached to the PC. The end user must activate the OS by logging on to the Microsoft website with the PC and enter the Product Key.

Windows® 7 Pro for Embedded Systems (FES 7 Pro) is a full version of Windows® 7 Pro. This powerful operating system will run any program that will run on a PC, including in XP mode. All of the features and functionality that customers expect to find on their desktop PC are available in this version.

Included Apps:
  • Internet Explorer
  • MS Word Viewer
  • Adobe PDF Viewer
  • MS PowerPoint Viewer
  • MS Excel Viewer
  • Media Player
Windows® Embedded Standard 7
Supported Models : See specific product pages for more information

WS7P also known as "Windows® Standard 7 Pro"

The Product Key is embedded in the PC and activated by Maple Systems. If the OS needs to be reinstalled, it must come back to the Maple Systems.

Windows® Embedded Standard 7 (WS7P) has a smaller footprint than full Windows® 7 and is perfect for applications that require additional software such as the Windows® Office suite.

Included Apps:
  • Internet Explorer
  • MS Word Viewer
  • Adobe PDF Viewer
  • MS PowerPoint Viewer
  • MS Excel Viewer
  • Media Player


Linux®-Compatible Options

The GNU / Linux®Operating System gives you a very flexible, dependible platform on which to build your application. Getting a system with the Linux®OS pre-installed takes the guesswork out of finding compatible hardware. Ubuntu®gives you a large community of support, a convenient and extensive package repository and extensive documentation.


Ubuntu®Linux®Desktop 20.04 LTS Focal Fossa
Supported Models :BPC2310, BPC2311 and BPC2330

This powerful Operating System delivers enterprise manageability and security to IoT solutions. Additionally, all of the features and functionality that customers expect to find on their desktop PC are available in this version. The Long Term Servicing Channel (LTSC) version ensures long term stability that critical production systems require by updating only necessary operating system components, with significantly fewer update interruptions.

Included Apps:
  • Gnome Desktop
  • Mozilla Firefox web browser
  • Libre Office Suite
  • Rythm Box Media Player
Ubuntu®Linux®Server 20.04 LTS Focal Fossa
Supported Models :BPC2310, BPC2311 and BPC2330

This slim yet powerful option has all the tools you need with none of the bloat you don't. Save space by skipping the desktop and get only what you need to get the job done.

Included Apps:
  • Open SSH server
  • VIM Text Editor
  • Apptitude Package Manager
  • Apache2
Documentation & Resources
Here's the list of documents and resources
Need additional support?
Contact Us
Certifications
CE RoHS FCC Class A IP20
In the Product Box
  • BPC2330A Industrial Box PC
  • Warranty Statement
  • Installation Instruction
  • Product Brochure
  • Input Power Cable
  • Digital I/O 10-pin Header Connector
  • Support DVD
  • Windows Recovery DVD
